Mengpaneel

  • Met multi-track recorder, audio-interface en DAW-bedieningsfuncties
  • 10-Kanaals mengpaneel
  • 12-Track recording in WAV/BWF-formaat op SD/SDHC/SDXC-kaarten tot 128 GB
  • 44,1 / 48 kHz
  • 16 / 24 Bit
  • 1-Knops compressor voor alle ingangskanalen
  • Schakelbare low-cut
  • 3-Bands EQ met swept mids voor alle mono-kanalen
  • Master EQ
  • Overdub recording
  • Punch in/out
  • Geïntegreerde audio-interface voor 12 kanalen (10 ingangen plus stereosom)
  • LC display
  • LED-meter met 12 segmenten
  • Geïntegreerde effect processor
  • Schakelbare fantoomspanning +48 V
  • Incl. netvoeding
  • Afmetingen (B x H x D): 343 x 99 x 360 mm
  • Gewicht: 4,3 kg
  • Bijpassende beschermhoes: art. 497194 (niet bij de levering inbegrepen)
  • Bijpassende koffer: art. 504823 (niet bij de levering inbegrepen)

Aansluitingen:

  • 8 x Microfoon/Line input combo XLR/Jack 6,3 mm (kanalen 1-6, 7, 9 kunnen worden gebruikt als instrumentingangen)
  • 2 x Line output XLR
  • 2 x Sub-uitgang 6,3 mm Jack
  • 2 x AUX-uitgang 6,3 mm Jack
  • 2 x Insert 6,3 mm Jack (kanaal 1+2)
  • Voetschakelaaringang: 6,3 mm Jack
  • Klikuitgang 6,3 mm Jack met tap-tempo-functie
  • 2 x Stereohoofdtelefoonuitgang 6,3 mm Jack
  • MIDI-ingang en -uitgang
  • USB
  • Leverbaar sinds Mei 2020
  • artikelnummer 483453
  • verkoopseenheid 1 stuk
  • Number Of Tracks 12
  • Simultaneous Recording: Amount Of Tracks 12
  • Effects Yes
  • Storage Medium SD/SDHC/SDXC
  • Phantom power Yes
  • XLR Connectors 8
  • Jack Connectors 8
  • RCA Connectors Yes
  • MIDI Interface 1x In, 1x Out
  • USB connection Yes
  • Digital Connections USB
  • Miscellaneous Connectors Foot Switch
  • Headphone connection Yes
  • USB Yes
  • Recording / Playback Channels 12x12
  • Max.number of input channels 10
  • Microphone Inputs 8
  • Bluetooth Yes
  • Number of Mic Inputs 8
  • 5-pole DIN MIDI Yes
  • Analog Line Inputs 10
  • Number of Line Inputs 10
  • Analog Line Outputs 2x Jack, 2x XLR
  • Instrument Inputs 8
  • Number of Line Outs 4
  • Digital Inputs 0
  • Fader 12
  • Headphone Outs 2
  • Rotary Encoders 12
  • Digital Outputs 0
  • Audio I/O Yes
  • Number of S/PDIF Connectors 0
  • Word Clock No
  • Number of ADAT Connectors 0
  • Transport Function Yes
  • Numer of AES/EBU Connectors 0
  • Footswitch connection Yes
  • Number of MADI Connectors 0
  • Computer interface USB
  • MIDI-interface Yes
  • Other Connectors USB
  • Special Features Recording on SD Card
  • MIDI interface Yes
  • Options -
  • Additional Features Mixer and Multitrack Recorder
  • Max. sample rate (kHz) 48 kHz
  • Max. resolution in bit 24 bit
  • Incl. power supply Yes
  • USB Version 2.0
  • Width in mm 343 mm
  • Depth in mm 360 mm
  • Height in mm 99 mm
  • Included in delivery Power Supply (Tascam PS-M1524), USB Type C to USB Typ A cable, TRRS cable, manual
  • Zero latency monitoring Yes
  • Connection Format USB port Type C
B-Stock vanaf € 579 beschikbaar
€ 624
Alle prijzen incl. btw
Direct leverbaar
Direct leverbaar

Dit product is op voorraad en kan direct verzonden worden.

Informatie over de verzending
1
106
Bezoeker
bekijken dit product
2
Best seller rang
in meersporen compactstudios

159 Klantenbeoordelingen

4.7 / 5

U moet ingelogd zijn om producten te evalueren.

Note: Om te voorkomen dat evaluaties gebaseerd zijn op roddel, geruchten of heimelijke advertentie staan wij op onze website alleen evaluaties toe van daadwerkelijke gebruikers die het geevalueerde product bij ons gekocht hebben.

Na inloggen vindt u alle producten die u kunt evalueren ook onder “Product evalueren” in uw klantencentrum.

bediening

features

geluid

afwerking

104 Recensies

T
alleskunner
Thuur 12.01.2023
Je kunt m zowel als interface voor je DAW, DAWless met een MPC of ouderwets als stand alone multitracker gebruiken. Moet signaal wel ff stevig insturen om niet te veel ruis te krijgen. Verder de vertrouwde TASCAM kwaliteit.
bediening
features
geluid
afwerking
0
0
Evaluatie melden

Evaluatie melden

G
GEWELDIG✌🏽✌🏽✌🏽✌🏽
Goldcoco 11.12.2024
Ik heb heel veel plezier aan deze mixer. Is je geld zeker waard. Ik gebruikt het voor live optreden en ook in de studio.
bediening
features
geluid
afwerking
0
0
Evaluatie melden

Evaluatie melden

google translate gb
Helaas is er een fout opgetreden, probeert u het a.u.b. later nogmaals.
S
Magic Mix
Stephen662 30.07.2020
'Brilliant build quality' was the first thing I said to myself as I popped the box. Having read the manual back to front many times whilst waiting on delivery, I found that in half an hour I had set up and ready to go - card formatted, click track working, synced to BFD3 and USB audio streaming out of BFD into a pair of channels.

All I can say is that Tascam have really nailed it with this one, and if they put MIDI etc on the 24 track it would be a truly pro workhorse. However, 10 track recording (and 2 master track) are adequate for my needs; primarily used out of my studio to record jam sessions with buddies.

If you want to get really picky then here's the dirt:

1/ Only two insert points (but appreciate the cost implications of putting them on all channels). I must say though a pair of master inserts would have been nice.

2/ Only 2 fx sends. Again a cost issue - also no dedicated simple returns. If you use the built in FX you are good to go, but if you patch in a box then you are going to lose 2 channels for a stereo return.

3/ Tascam must be the master if syncing to other gear or your DAW. Does not worry me.

EVERYTHING else is just brilliant and a lovely sounding machine it is. Tascam have a certain magic, especially with digital gear. Blindfold, you would swear it is analogue, but to be fair its better than that.

Conclusion, money well spent. Great value, simple to use, and all you need to do is RTFM :)
43
3
Evaluatie melden

Evaluatie melden

google translate gb
Helaas is er een fout opgetreden, probeert u het a.u.b. later nogmaals.
HP
Class Compliant Great, But...
HDS Productions 15.07.2024
I purchased the Model 12 for two big reasons.

1. To use as class compliant gear with my MPC
2. To be a (dawless) home studio mixer and recorder

First, the Model 12 works very well with the MPC, being able to create separate tracks from the MPC and then mix each one before recording. I also loved the Tascam's ability to do overdub recording. However, when it came time to mix a couple of hardware synths and vocals for output, the unit's limitations became glaringly obvious. Vocals especially mixed very low, even with gain up to a maximum. In my opinion there is absolutely no way to create a completed recording with the Model 12 without a good deal of time and work in a DAW. While this may not be an issue for some, I personally just don't see the point with owning a mixer with such limitations when it comes to music production.

I think this is a good case for 'you get what you pay for', but ask yourself what your expectations and goals are, because apart from natural talent the gear you own and use needs to support where you are trying to get to. And, with that old adage; I did end up switching to an RME audio interface that costs twice as much, but is twice as much and more in superiority.

With that said, there are other audio interface options at lower price points that can do the job from manufacturers like Motu, Arturia and SSL to name a few.
bediening
features
geluid
afwerking
3
3
Evaluatie melden

Evaluatie melden
